Power Supplies for Switches & Chassis

A switch power supply is a replaceable unit that powers the switch and, like the fans, has one fixed airflow direction.

Power supply units for switches and enterprise chassis from any maker. Two specifications must match before wattage is considered. Airflow direction: PSU fan direction has to match the switch it is installed in, and a mismatched unit will fight the chassis airflow and trigger thermal shutdown. Form factor and connector: PSUs are chassis-specific and are not portable between switch families. Confirm the exact switch model and airflow direction with us before ordering.

How this line is built

Power supplies and fans are refurbished and remanufactured in their own recovery lane.

They go into the switches we build to order, and are sold on their own in this product line.

How we build

How to choose

The NVIDIA power supply for each switch, in each airflow direction. P2C: air enters at the power side and leaves at the port side. C2P: the other way round.

SwitchP2C power supply (blue)C2P power supply (red)Power
SN2410, SN2700, SN2740; SB7700, SB7800, SB7890; SX1410, SX1710, SX6710MTEF-PSF-AC-IMTEF-PSR-AC-I550W AC
SN2410, SN2700, SN2740 (older units, discontinued)MTEF-PSF-AC-AMTEF-PSR-AC-A460W AC
SN3420MTEF-PSF-AC-EMTEF-PSR-AC-E550W AC
SN3700, SN3700C, SN4600C, QM8700, QM8790MTEF-PSF-AC-CMTEF-PSR-AC-C1100W AC
SN4600MTEF-PSF-AC-FMTEF-PSR-AC-F1500W AC
QM9700, QM9790MTEF-PSF-AC-KMTEF-PSR-AC-K2000W AC
SN5400930-9SPSU-00FA-00B930-9SPSU-00RA-00B3kW AC
SN5600None: the SN5600 is C2P only930-9SPSU-00RA-00B3kW AC

Sources: NVIDIA SN2000 switch manual, replacement parts, NVIDIA SN3000 switch manual, replacement parts, NVIDIA SN4000 switch manual, replacement parts, NVIDIA QM8700 switch manual, replacement parts, NVIDIA QM9700 switch manual, replacement parts, NVIDIA SN5000 switch manual, replacement parts, NVIDIA SN5000 switch manual, installation.

Buying switch power supplies from T.E.S

T.E.S IT-SOLUTIONS sells new and refurbished power supplies online. Each product page gives the part number, condition, price and stock. For example, see the MTEF-PSF-AC-A.

Which airflow direction does my power supply need?
The same as the fans and the other power supply in the switch. MTEF-PSF parts are P2C: air enters at the power side and leaves at the port side, and the handle is blue. MTEF-PSR parts are C2P, with a red handle. NVIDIA says a mismatch in airflow affects the cooling of the switch.Source: NVIDIA SN2000 switch manual 2 3
Can I replace a power supply while the switch is running?
Yes on most NVIDIA switches: the SN2000, SN3000, SN4000, QM8700, QM9700 and SB7700/SB7800 manuals say the two power supplies work in a redundant configuration and either one may be taken out without bringing the switch down. Do not leave an SN2410 power supply slot empty for more than 5 minutes. SN5400 and SN5600 switches with power supplies of revision S3 or below must be shut down first.Source: NVIDIA SN2000 switch manual; NVIDIA SN3000 switch manual; NVIDIA SN4000 switch manual; NVIDIA QM8700 switch manual; NVIDIA QM9700 switch manual; NVIDIA SB7700/SB7800 switch manual; NVIDIA SN5000 switch manual
Is the MTEF-PSF-AC-A still made?
No. NVIDIA lists the 460W MTEF-PSF-AC-A and MTEF-PSR-AC-A as discontinued, replaced by the 550W MTEF-PSF-AC-I and MTEF-PSR-AC-I for the SN2700, SN2740 and SN2410.Source: NVIDIA SN2000 switch manual
How long does shipping take?
We ship worldwide from Haifa, Israel. Orders leave within 1–3 business days. Standard shipping takes 8–13 business days, and traceable EMS takes 4–7.
What warranty and return terms apply?
Every product has a 30-day warranty. You can return an unused item in its original packaging within 30 days of delivery, and you pay the return shipping. Store policy
How do I buy?
Add a part to the cart and pay by card at checkout, or ask for a quote and pay by bank transfer. We reply to quote requests within 1 business day. Prices are in euros.
Do you accept purchase orders, and do you charge VAT?
We accept purchase orders. We reply with a pro-forma invoice, and the order ships once payment arrives. Orders shipped outside Israel are exports, so we charge no VAT. Import VAT and duty, if any, are paid by the buyer in their own country.
