NVIDIA Mellanox MC2206130-001 Cable QSFP DAC 1m FDR10 40Gb/s VPI (Lot of 5)

Part no.MC2206130-001

€62.00

In stockCondition: Refurbished

Request a quote

Checkout runs on the secure Wix checkout page.

Where to buy the MC2206130-001 Lot of 5: T.E.S IT-SOLUTIONS sells the MC2206130-001 Lot of 5 at €62, in stock, and ships worldwide from Haifa, Israel.

How this unit is built

Recovered from end-of-life equipment, inspected and tested before it ships.

See the production flow
MC2206130-001_Lot of 5Tap the photo for full size
NVIDIA Mellanox MC2206130-001 Cable QSFP DAC 1m FDR10 40Gb/s VPI (Lot of 5), photo 1 of 1

Description

NVIDIA Mellanox MC2206130-001 FDR10 40Gb/s QSFP to QSFP Passive Copper DAC, 1m: This is a 1m passive copper Direct Attach Cable (DAC) for FDR10 InfiniBand 40Gb/s and 40GbE Ethernet connectivity over a fixed-length QSFP to QSFP assembly. This is a passive (un-amplified) copper assembly, not an active optical or active copper cable, and not a transceiver with a separate patch cord. Condition: Refurbished — Tested by T.E.S IT-SOLUTIONS, supplied as a Lot of 5.

Engineering Context

The MC2206130-001 is a Mellanox VPI-class passive copper assembly, meaning the cable can carry either FDR10 InfiniBand at 40Gb/s (4x10Gb/s) or 40GbE Ethernet on host ports configured for the corresponding mode. It uses a QSFP form factor on both ends with integrated EEPROM that lets the switch and adapter identify the cable's length and rated data rate. At 1m, copper is the standard physical layer at 40Gb/s — far cheaper than QSFP+ SR4 transceivers with MPO patch cords for short runs. Being passive, the cable consumes no host power and adds zero per-port heat budget.

Deployment & Use Cases

40Gb/s InfiniBand FDR10 fabric runs between switches and host adapters within a single rack or to an adjacent rack. 40GbE Ethernet inter-switch links in mixed-mode VPI fabrics. Compute-cluster expansions where the existing infrastructure is FDR10-class and matching cables are required. Refresh/replacement of failed cables in long-running 40Gb/s installations.

Technical Specifications

OEM: NVIDIA Mellanox
Part Number: MC2206130-001
Form Factor: QSFP to QSFP (Point-to-Point)
Cable Type: Passive Copper DAC
Length: 1m
Data Rate (IB): FDR10 InfiniBand 40Gb/s (4x10Gb/s)
Data Rate (Ethernet): 40GbE (VPI mode)
Protocol: VPI — InfiniBand FDR10 or Ethernet 40GbE
Conductor: Copper (twin-axial)
Power: 0 W (passive)
Pack: Lot of 5
Condition: Refurbished — Tested by T.E.S IT-SOLUTIONS

Compatibility & Hard Constraints

Compatible with Mellanox FDR10/QDR-class InfiniBand switches (e.g., SX6036, SX6005, IS5000 series) and ConnectX-2 / ConnectX-3 / ConnectX-3 Pro host adapters configured for InfiniBand or 40GbE VPI mode. Will operate as a 40GbE Ethernet cable when both endpoints are configured for Ethernet. Not compatible with EDR (100Gb/s) QSFP28 ports — this is a QSFP form factor cable rated for FDR10. Not a breakout cable; does not split into 4xSFP+. Fixed 1m length.

Why Choose T.E.S IT-SOLUTIONS

T.E.S IT-SOLUTIONS checks every cable before shipment (see Inspection and checks). We provide expert consultation on InfiniBand/VPI fabric cabling and global shipping. Standard handling time is 1–3 business days.

Frequently Asked Questions

What data rate (ib) does the MC2206130-001 have?

The MC2206130-001 data rate (ib) is FDR10 InfiniBand 40Gb/s (4x10Gb/s).

What is the MC2206130-001 NOT compatible with?

This is a passive (un-amplified) copper assembly, not an active optical or active copper cable, and not a transceiver with a separate patch cord. Confirm fitment against your platform before ordering MC2206130-001.

What condition is the MC2206130-001 supplied in, and who sells it?

The MC2206130-001 is supplied in Refurbished condition by T.E.S IT-SOLUTIONS from Haifa, Israel, with 1-3 business day handling and worldwide B2B shipping.
