NVIDIA Mellanox MSX6518-6R 288-Port FDR 56Gb/s InfiniBand Director Switch: This is a director-class modular InfiniBand chassis from the Mellanox SX6518 series, populated with 288 active FDR 56Gb/s ports. The system is a fully managed non-blocking InfiniBand switch built around a leaf/spine internal fabric, and supports the InfiniBand Trade Association FDR specification. This is a chassis switch with installed leaf and spine modules, not a 1U pizza-box switch and not a bare empty chassis. This is a refurbished unit.
Engineering Context
The MSX6518 chassis is engineered as a director-class FDR switch. As shipped, this unit has 288 FDR ports active. Each port runs at 56Gb/s (4x 14Gb/s lanes) over QSFP+ optics or copper, delivering aggregate fabric bandwidth in the multi-Tb/s range. Power is delivered via 6 N+N redundant power supplies and cooling via 4 fan trays, both serviceable from the rear. Management is single-management-module configuration. The chassis is designed for HPC and large enterprise InfiniBand fabrics requiring centralized aggregation rather than distributed leaf-spine pizza-box topologies.
Deployment & Use Cases
Core/aggregation switch in HPC clusters running MPI workloads over FDR InfiniBand. Centralized fabric for storage backends using SRP, iSER, or NVMe-oF over InfiniBand. Large enterprise data center InfiniBand consolidation where a single director chassis replaces multiple top-of-rack edge switches. Universities and research labs running CFD, molecular dynamics, and weather modeling on FDR-class compute nodes.
Technical Specifications

OEM: NVIDIA Mellanox
Part Number: MSX6518-6R
Chassis Family: SX6518 Director Switch
Active Ports: 288 (of chassis maximum)
Port Speed: FDR 56Gb/s per port (4x 14Gb/s)
Connector Type: QSFP+
Protocol: InfiniBand FDR
Switching: Non-blocking (with all required spines populated)
Management: Fully Managed, single management module
Power Supplies: 6x N+N redundant
Fan Trays: 4 included
Compliance: RoHS6
Condition: Refurbished — Tested by T.E.S IT-SOLUTIONS

Compatibility & Hard Constraints
Pairs with Mellanox ConnectX-3 FDR HCAs and other FDR-capable host adapters. Interoperable with Mellanox SX6000-series edge switches in mixed director-and-edge fabrics. QSFP+ ports accept Mellanox FDR DACs (e.g., MC2207130 series), FDR AOCs, and FDR optical transceivers. Not an EDR (100Gb/s) or HDR (200Gb/s) switch — port speed is fixed at FDR 56Gb/s. Requires data-center-grade rack space, three-phase or appropriately rated AC input, and structured cooling. Non-blocking operation depends on having all spine modules populated; verify spine module count if non-blocking is required for the target workload. Heavy chassis (112 kg shipping weight) — site survey for rack capacity and lifting equipment is required.
